MariaDB Replication: Master-Slave Architecture

MariaDB Replication Architecture

A complete guide to deploying unidirectional Master-Slave replication on a Cloud VPS. Optimize read performance, ensure data redundancy, and manage remote synchronization.

Architecture Overview

The architecture consists of a single Master Node hosted on a Cloud VPS, handling all write operations. Multiple Slave/Client Nodes connect via a secure unidirectional stream to replicate data in real-time. This ensures high availability for read operations and robust backup capabilities.

☁️

VPS Cloud Master

MariaDB Server (Write/Read)

IP: Public Static IP

BinLog Stream (Port 3306)

🖥️

Client A

Read Replica

💻

Client B

Read Replica

📊

Analytics

Read Replica

🛡️ Network & Security

The VPS must expose the MariaDB port to the specific IP addresses of the clients to allow the replication stream.

Required Port

TCP 3306

Firewall Configuration (Linux/UFW)

                            # Allow specific client IP

                            sudo ufw allow from 192.168.1.50 to any port 3306

                            # OR allow anywhere (Not Recommended without VPN)

                            sudo ufw allow 3306/tcp

                            # Reload firewall

                            sudo ufw reload

👤 User Permissions

A dedicated user on the Master is required for slaves to authenticate and request updates.

SQL Commands (Run on Master)

                        -- Create User

                        CREATE USER 'replicator'@'%' IDENTIFIED BY 'SecurePass123!';

                        -- Grant Replication Privileges

                        GRANT REPLICATION SLAVE ON *.* TO 'replicator'@'%';

                        -- Apply Changes

                        FLUSH PRIVILEGES;

Note: Replace '%' with specific Slave IPs for better security (e.g., 'replicator'@'192.168.1.50').

Configuration Parameters (my.cnf)

Hypothetical configuration ready for implementation. Ensure unique server-ids.

VPS Master Config

Path: /etc/mysql/my.cnf

                            [mysqld]

                            # Unique ID for the Master

                            server-id = 1

                            # Enable Binary Logging (Crucial)

                            log_bin = /var/log/mysql/mysql-bin.log

                            # Network Binding

                            bind-address = 0.0.0.0

                            # Table Name Handling

                            lower_case_table_names = 1

                            # Optional: Specific DB Sync

                            # binlog_do_db = my_app_db

Client/Slave Config

Path: /etc/mysql/my.cnf

                            [mysqld]

                            # Unique ID (Different from Master)

                            server-id = 2

                            # Enable Relay Log

                            relay-log = /var/log/mysql/mysql-relay-bin.log

                            # Read-Only Mode (Recommended)

                            read_only = 1

                            # Table Name Handling (Must match)

                            lower_case_table_names = 1

                            # Connection Retry

                            slave_net_timeout = 60

Replication Lifecycle & Control

1. Initialization

Capture the Master's current state.

FLUSH TABLES WITH READ LOCK;

SHOW MASTER STATUS;
// Note File & Position

2. Activation (Slave)

Configure the link on the client/slave.

CHANGE MASTER TO
MASTER_HOST='VPS_IP',
MASTER_USER='replicator',
MASTER_PASSWORD='pass',
MASTER_LOG_FILE='mysql-bin.00001',
MASTER_LOG_POS=1234;

3. Management

Start, stop, and monitor synchronization.

Performance Impact: Read Scaling

By offloading read operations to slave nodes, the Master VPS preserves resources for write operations. The chart below illustrates the hypothetical increase in Total Read Operations Per Second (QPS) as clients are added.

💾 Backup & Restore

Essential commands for initial synchronization and disaster recovery.

Export (Backup)

Create a dump including master status.

mysqldump -u root -p --all-databases --master-data > full_backup.sql

Import (Restore)

Apply to Slave/Client before starting.

mysql -u root -p < full_backup.sql
